IS-2M

« Back to List« Go to the U.S.S.R. Tech Tree
5 400
IS-2M
This vehicle is a modification of the IS-2, developed from the early 1950s through the early 1960s. Before the T-10's development, the IS-2 was the main Soviet heavy tank. It remained in service until the mid 1990s. The tank chassis, power unit and turret were significantly changed. Some chassis components were adopted from the IS-3, as well as the splash shields and spare parts kit. The rear machine gun was removed from the turret. It was replaced with an additional fan for the fighting compartment. All gun embrasures were sealed. In addition, the standard engine was replaced with the V-54K-IS engine. The ammo capacity was increased to 34–35 shells, while the standard gun (the 122 mm D-25) remained unchanged. However, the gun elevation mechanism was improved. Some vehicles were equipped with the TVN-2 night-vision devices. Besides this, the new R-113 radio was equipped instead of the standard one. In addition, the driver's observation devices were improved.

122 mm D-25T

IS-2M

R-113

V-54K-IS

IS-2M

Shell Types:

AP
APCR
HE

Equipment:

Consumables:

These characteristics apply to the vehicle with the crew trained to 100%.

Firepower:

Ammunition35 (rounds)
Caliber122 (mm)
Damage390 / 390 / 530 (HP)
Penetration175 / 217 / 61 (mm)
Rate of Fire4.88 (rounds/min)
Average Damage per Minute1902 (HP)
Shells in the Magazine
Time for Loading Between Shots  (s)
Time for Complete Loading  (s)
Gun Loading12.30 (s)
Aiming Time3.30 (s)
Dispersion at 100 m0.45 (m)

Mobility:

Weight/Load Limit48.50 / 52.00 (t)
Engine Power600 (h.p.)
Specific Power12.37 (h.p./t)
Top Speed34 (km/h)
Reverse Speed14 (km/h)
Traverse Speed36 (deg/s)
Turret Traverse Speed28 (deg/s)

Survivability:

Hit Points1300 (HP)
Hull Armor100 / 90 / 60 (mm)
Turret Armor100 / 90 / 90 (mm)

Spotting:

View Range350 (m)
Signal Range730 (m)


Crew:

Commander(Radio Operator)
Gunner
Driver
Loader
